Pipeline Design for DART Cotton Belt Commuter Rail

Prior to joining LJB, Grantham & Associates performed pipeline design, construction surveying and as-built drawings for 39,000 linear feet of pipeline relocation. Construction methods included open cut and HDD. The project included relocation of 12-inch refined product pipeline ahead of DART’s 26-mile Cotton Belt “Silver Line” commuter rail project. This large project was completed in phases, which was completed as 19 separate projects, spanning seven cities in the Dallas-Fort Worth metroplex.
